Pressure and temperature
working pressure | PN10, PN16 |
testing pressure | shell: 1.5 times rated pressure seat: 1.1 times rated pressure |
working temperature | -10 °C to 80°C (NBR) -10 °C to 120°C (EPDM) |
suitable media | water, oil and gas |
Main material list
parts | material |
body | cast iron, ductile iron, |
seat | EPDM, NBR,VITON, PTFE |
disc | nickel ductile iron,AI bronze, stainless steel |
stem | carbon steel, stainless steel |
bushing | PTFE |
"O" ring | PTFE |
pin | stainless steel |
key | stainless steel |
Executive Standard:
Design Standard | EN 593 , MSS SP67 API 609 BS5155 |
Inspection & Test | API 598 ISO 5208 EN 12266 |
End Standard | ANSI B16.1 CL. 125LB & B16.5 CL. 150LB AS 2129 Table D & E BS 10 Table D & E DIN 2501 PN6, PN10 & PN16 EN 1092 PN6, PN10 & PN16 ISO 2531 PN6, PN10 & PN16 ISO 7005 PN6, PN10 & PN16 KS B 1511 / JIS B 2210 5K & 10K MSS SP44 CL. 150LB AWWAC207 SABS 1123 Table 1000/3 & Table 1600/3 |
Face to Face | ISO 5752 , EN 558 , MSS SP67 and API 609 DIN3202 |
Top Flange | ISO 5211 |
Name: Cast iron rubber seat Butterfly Valve Water Type
Standard: EN 593 , MSS SP67 API 609 BS5155
Model Number: Forged Steel Valve
Power: Manual and electric
Port Size: 1/4" to 2"
Temperature: -196C~450C
Material: A105/F5/F11/F22/304/304L/316/316L/LF2
Top Flange: ISO 5211
Connection Ends: Flanged
Class: Class150~class2500
Operation: Hand wheel
Medium: Water,Oil,Gas,Steam and chemical liquid.
Pipefun Pipe keeps more than 2000 tons stocks at hand, we offer one stop buying and fast delivery. Full sizes and full standards products are available. We also have ISO and API 5L certificates.
Pipefun is the relaible partner for project solution and long time business relationship! Free inquiry for good price!
Hebei Pipefun Pipe and Fitting facility Co., Ltd., is established in 2000, it is a specialized enterprise professional in producing steel pipes and pipe fittings. Choosing us to be your business partner can bring you great advantages in business! There are 25 engineers and 89 skilled workers in our factory.
Tell us the required size, material, quantity and destination. Our team will reply with a suitable quotation.
